Product Name: 0.6/1KV XLPE Insulated power cable(YJV22 YJV23 YJV32 YJV33 YJV YJLV YJLV22 YJLV23 YJLV32 YJLV33)
This product applies to fixed wiring of power distribution network or industrial device with rated power-frequency voltage≦0.6/1KV.
technical parameter
Nominal section |
Approximate diameter of conductor |
Insulation Thickness |
Sheath nominal thickness |
Approximate outer diameter of cable |
Approximate weight of cable |
The direct current resistance of the conductor is not greater than that at 20. |
||
mm2 |
mm |
mm |
mm |
mm |
YJV |
YJLV |
YJV |
YJLV |
2×2.5 |
1.8 |
0.7 |
1.8 |
11.4 |
152 |
121 |
7.41 |
12.1 |
2×4 |
2.3 |
0.7 |
1.8 |
12.4 |
199 |
149 |
4.61 |
7.41 |
3×2.5 |
1.8 |
0.7 |
1.8 |
12.0 |
188 |
142 |
7.41 |
12.1 |
3×4 |
2.3 |
0.7 |
1.8 |
13.0 |
254 |
179 |
4.61 |
7.41 |
4×2.5 |
1.8 |
0.7 |
1.8 |
12.8 |
230 |
168 |
7.41 |
12.1 |
4×4 |
2.3 |
0.7 |
1.8 |
14.0 |
316 |
217 |
4.61 |
7.41 |
